SS304 LPG liuqiud petroleum gas needle valve 2mm to 32mm Diameter

Product Details:

Place of Origin:	China
Brand Name:	Purescience
Certification:	ISO9001/ISO
Model Number:	YZF4-2N

Payment & Shipping Terms:

Minimum Order Quantity:	200 pieces
Price:	negotiable
Packaging Details:	carton and pallet
Delivery Time:	2 to 3 weeks
Supply Ability:	100000 pieces per month

Contact Now

Detailed Product Description

Product Name:	Cutting Ferulle Needle Valve YZF4-2N	Model:	YZF4-2N
Diameter:	2mm To 32mm	Pressure Rating:	PN0.6 Mpa To PN80 Mpa
Temperature Range:	-190 ℃ To 220 ℃ ( 70 ℃ To 570 ℃ )	Material:	1Cr18Ni9Ti , SS304 , 316, 316L , 12Cr1Mov , TA2 , F55 , C-276 , F51
Standards:	GB / JB / ANSI / HG / API / DIN	Media Type:	Water, Oil, Gas, Many Types Of Liquid Fluid Media
End Port Connect:	Cutting Ferrule
Highlight:	high pressure needle valve , water stop valve

Cutting ferrule needle valve for LPG liuqiud petroleum gas PN0.6 Mpa to PN120 Mpa DN2 to DN32

Specifications

Pressure rating: PN0.6 - 80Mpa
Cutting Ferrule pipe diameter: 2mm -50mm
Temperature range: -190 ℃ to 220 ℃ (or 70 ℃ to 570 ℃ )
Suitable fluid media: oil, water, gas and many other corrossive or non-corrosive liquid fluid
Material of construction: 1Cr18Ni9Ti , SS304 , 316, 316L , 12Cr1Mov , TA2 , F55 , C-276 , F51
Flow direction: bi-direction
Driven: manually driven
End Port connection: cutting ferrule
Standards: GB / JB / ANSI / HG / API / DIN

No.	Port Diameter	Pressure range PN (MPa)	Pipe OD (D0)	Pipe OD (D1)	H1 (mm)	H2 (mm)	L (mm)
1	DN5mm to DN65 mm	PN0.6 Mpa to PN80 Mpa	6	6	64	70	70
2	DN5mm to DN65 mm	PN0.6 Mpa to PN80 Mpa	8	8	64	70	70
3	DN5mm to DN65 mm	PN0.6 Mpa to PN80 Mpa	8	6	64	70	70

Description

No end to applications of pipe fittings, so long no end to the applications of pipes . The list of piping applications continues to expand, its strength, flexibility, very good flow rates and high chemical resistance are qualities which are uniquely suited for the movement or transfer of liquids, steam, solids and air from one point to another. With piping, pipe fittings have many other uses like as follows:

The transfer of extremely hazardous materials such as chemical and waste.
Protection of sensitive equipment from high pressures.
Protection from corrosion and other extreme weather conditions.
Resistance to household and industrial chemicals.

Applications

Chemical / Petrochemical
Municipal
Food, Beverage, and Dairy
Oil and Gas
Power
Process Instrumentation
Pulp and Paper
Semiconductor
Marine & dredging
Sanitation
Irrigation
Residential
Road & highway construction
Ventilation etc

Competitive advantage

AutoCAD is used to design products and optimize structures
Cast Process Design by by Castsoft CAD and CAE
Strict Manufacturing Process control
Quality Control Of The Casting Material
Metal Material Laboratory for test of compositional, metallographic & mechanical property
Perfect apperance
