PN16 Mpa Socket weld metal tube fitting for Marine & dredging

Product Details:

Place of Origin:	China
Brand Name:	Purescience
Certification:	ISO9001/ISO
Model Number:	YZG-4

Payment & Shipping Terms:

Minimum Order Quantity:	2000 pieces
Price:	negotiable
Packaging Details:	carton and pallet
Delivery Time:	2 to 3 weeks
Payment Terms:	L/C, T/T, D/P
Supply Ability:	100000 pieces per month

Contact Now

Detailed Product Description

Product Name:	Stell Tube Fitting With Double Ferrules YZG-4	Model:	YZG-4
Diameter:	4 Mm To 18mm ( 1/8", 3/16", 1/4", 5/16" 3/8" 1/2" 5/8"	Pressure Rating:	PN16 Mpa
Temperature Range:	< 450 ℃	Material:	1Cr18Ni9Ti , SS304 , 316, 316L , 12Cr1Mov , TA2 , F55 , C-276 , F51
Standards:	GB / JB / ANSI / HG / API / DIN	End Port Connect:	Cutting Ferrules
High Light:	high pressure needle valve , water stop valve

Socket weld Straight tube fitting for pipe connection tube system PN16 Mpa 1/8" - 5/8"

Specifications

Pressure rating: PN16 Mpa- 120Mpa
Pipe diameter: 4mm -18mm ( 1/8" to 5/8" )
Temperature range: up to 450 ℃
Material of construction: 1Cr18Ni9Ti , SS304 , 316, 316L , 12Cr1Mov , TA2 , F55 , C-276 , F5
End Port connection: cutting ferrule
Standards: NPT / ANSI / UN

Tube OD.	Standard	Thread (mm)	Thread (inch)
1/8"	NPT / ANSI / UN / GB	4 / 5 / 6 / 8 / 10 / 12 / 14 / 16 / 18 mm	1/8, 3/16, 1/4, 5/16 , 3/8, 1/2, 5/8
3/8"	NPT / ANSI / UN / GB	4 / 5 / 6 / 8 / 10 / 12 / 14 / 16 / 18 mm	1/8, 3/16, 1/4, 5/16 , 3/8, 1/2, 5/8
1/2"	NPT / ANSI / UN / GB	4 / 5 / 6 / 8 / 10 / 12 / 14 / 16 / 18 mm	1/8, 3/16, 1/4, 5/16 , 3/8, 1/2, 5/8
3/4"	NPT / ANSI / UN / GB	4 / 5 / 6 / 8 / 10 / 12 / 14 / 16 / 18 mm	1/8, 3/16, 1/4, 5/16 , 3/8, 1/2, 5/8
5/8"	NPT / ANSI / UN / GB	4 / 5 / 6 / 8 / 10 / 12 / 14 / 16 / 18 mm	1/8, 3/16, 1/4, 5/16 , 3/8, 1/2, 5/8

Description

No end to applications of pipe fittings, so long no end to the applications of pipes . The list of piping applications continues to expand, its strength, flexibility, very good flow rates and high chemical resistance are qualities which are uniquely suited for the movement or transfer of liquids, steam, solids and air from one point to another. With piping, pipe fittings have many other uses like as follows:

The transfer of extremely hazardous materials such as chemical and waste.
Protection of sensitive equipment from high pressures.
Protection from corrosion and other extreme weather conditions.
Resistance to household and industrial chemicals.

Applications

Chemical / Petrochemical
Municipal
Food, Beverage, and Dairy
Oil and Gas
Power
Process Instrumentation
Pulp and Paper
Semiconductor
Marine & dredging
Sanitation
Irrigation
Residential
Road & highway construction
Ventilation etc

Competitive advantage

AutoCAD is used to design products and optimize structures
Cast Process Design by by Castsoft CAD and CAE
Strict Manufacturing Process control
Quality Control Of The Casting Material
Metal Material Laboratory for test of compositional, metallographic & mechanical property
Perfect apperance
