High pressure cutting ferrule stop valve in measure pipeline PN0.6 Mpa to PN80 Mpa DW2 to DW65

Product Details:

Place of Origin:	China
Brand Name:	Purescience
Certification:	ANSI/AWWA/ASTM/ANSI/
Model Number:	YZF4-1A

Payment & Shipping Terms:

Minimum Order Quantity:	200 pieces
Price:	negotiable
Packaging Details:	carton and pallet
Delivery Time:	2 to 3 weeks
Supply Ability:	100000 pieces per month

Contact Now

Detailed Product Description

Product Name:	Stop Valve YZF4-1A	Pressure Rating 1:	PN0.6 Mpa To PN80 Mpa
Pipe Diameter:	2mm To 50mm	Media Type:	Water, Oil, Gas, Many Types Of Liquid Fluid Media
Temperature Range:	-190 ℃ To 220 ℃ ( 70 ℃ To 570 ℃ )	Material:	1Cr18Ni9Ti , SS304 , 316, 316L , 12Cr1Mov , TA2 , F55 , C-276 , F51
Standards:	ANSI / ASME / BSP / DIN	End Port Connect:	Cutting Ferrule
High Light:	high pressure needle valve , water stop valve

High pressure cutting ferrule stop valve in measure pipeline PN0.6 Mpa to PN80 Mpa DW2 to DW65

Specifications

Pressure rating: PN0.6 - 80Mpa
Cutting Ferrule pipe diameter: 2mm -50mm
Temperature range: -190 ℃ to 220 ℃ (or 70 ℃ to 570 ℃ )
Suitable fluid media: oil, water, gas and many other corrossive or non-corrosive liquid fluid
Material of construction: 1Cr18Ni9Ti , SS304 , 316, 316L , 12Cr1Mov , TA2 , F55 , C-276 , F51
Flow direction: bi-direction
Driven: manually driven
Port connect: cutting ferrule
Standards: ANSI/AWWA/ASTM/ANSI

No	Port diameter (mm)	Pressure rating PN (MPa)	OD of pipe (D0)	H1 (mm)	H2 (mm)	L (mm)
1	DN5mm to DN65mm	PN0.6 Mpa to PN80 Mpa	10mm	82	88	76
2	DN5mm to DN65mm	PN0.6 Mpa to PN80 Mpa	12mm	82	88	78
	DN5mm to DN65mm	PN0.6 Mpa to PN80 Mpa	14mm	82	88	86

Description

No end to applications of pipe fittings, so long no end to the applications of pipes . The list of piping applications continues to expand, its strength, flexibility, very good flow rates and high chemical resistance are qualities which are uniquely suited for the movement or transfer of liquids, steam, solids and air from one point to another. With piping, pipe fittings have many other uses like as follows:

The transfer of extremely hazardous materials such as chemical and waste.
Protection of sensitive equipment from high pressures.
Protection from corrosion and other extreme weather conditions.
Resistance to household and industrial chemicals.

Materials used:

Gun Metal
Cast Steel
Stainless Steel
Cast Iron
Alloy Steel
Brass
Bronze
Aluminum
Zirconium
Plastic etc.

Applications

Chemical / Petrochemical
Municipal
Food, Beverage, and Dairy
Oil and Gas
Power
Process Instrumentation
Pulp and Paper
Semiconductor
Marine & dredging
Sanitation
Irrigation
Residential
Road & highway construction
Ventilation etc

Competitive advantage

AutoCAD is used to design products and optimize structures
Cast Process Design by by Castsoft CAD and CAE
Strict Manufacturing Process control
Quality Control Of The Casting Material
Metal Material Laboratory for test of compositional, metallographic & mechanical property
Perfect apperance
