Flange gate valve for high pressure, high temperature steam transfer PN16 Mpa PN80 Mpa DN10 - DN40

Flange gate valve for high pressure, high temperature steam transfer PN16 Mpa PN80 Mpa DN10 - DN40

Flange gate valve for high pressure, high temperature steam transfer PN16 Mpa PN80 Mpa DN10 - DN40

Product Details:

Place of Origin: China
Brand Name: Purescience
Certification: ANSI/AWWA/ASTM/ANSI/
Model Number: YZF6-4G

Payment & Shipping Terms:

Minimum Order Quantity: 200 pieces
Price: negotiable
Packaging Details: carton and pallet
Delivery Time: 2 to 3 weeks
Supply Ability: 100000 pieces per month
Contact Now
Detailed Product Description
Product Name: Gate Valve YZF6-4G Model: YZF6-4G
Diameter: DN10mm To DN 40mm Pressure Rating: PN1.6 Mpa - PN6.4 Mpa, PN16Mpa PN80 Mpa
Temperature Range: -20 ℃ To 440 ℃ / -190 ℃ To 240 ℃ , 540℃ , 570℃ Material: 20#, 1Cr18Ni9Ti , SS304 , 316, 316L , 12Cr1Mov , TA2 , F55 , C-276 , Hastelloy
Standards: ANSI / ASME / BSP / DIN Media Type: Water, Oil, Gas, Many Types Of Liquid Fluid Media
End Port Connect: Flange

Flange gate valve for high pressure, high temperature steam transfer PN16 Mpa PN80 Mpa DN10 - DN25



Specifications

  • Material of construction: 1Cr18Ni9Ti , SS304 , 316, 316L , 12Cr1Mov , TA2 , F55 , C-276 , F51
  • End Port connection: Socket welding wrought
  • Sizes: DN5 mm to DN32 mm
  • Pressure grade: PN1.6 Mpa - PN6.4Mpa , PN16 Mpa , PN80 Mpa
  • Temperature range: -20 ℃ to 440 ℃  / -190 ℃ to 240 ℃ , 540℃ , 570℃
  • Applications:  any corrossive or non-corrosive liquid fluid
  • Standards: ANSI/AWWA/ASTM/ANSI
No. Dia. (DN) Pressure rating (PN / Mpa) D1 D H1 H2 L
1 DN15 16Mpa, 80Mpa, 1.6Mpa - 6.4Mpa 65 95 155 175 130
2 DN20 16Mpa, 80Mpa, 1.6Mpa - 6.4Mpa 75 105 170 190 150
3 DN25 16Mpa, 80Mpa, 1.6Mpa - 6.4Mpa 85 115 233 261 160
4 DN32 16Mpa, 80Mpa, 1.6Mpa - 6.4Mpa 100 135 266 302 190
5 DN40 16Mpa, 80Mpa, 1.6Mpa - 6.4Mpa 110 145 319 362 200



Description

The gate valve is also known by other names, such as knife valve, slide valve, stop valve, or block valve, since its primary purpose is to stop the flow. The valve has become an important piece of fluid control equipment for more than 150 years. The gate valve has become a one-stop solution for fluid control call with relatively little basic design change.

Gate valves are useful in applications involving slurries. This is because their “gates” can move right through the slurry.



Materials used:

  • Gun Metal
  • Cast Steel
  • Stainless Steel
  • Cast Iron
  • Alloy Steel
  • Brass
  • Bronze
  • Aluminum
  • Zirconium etc.

Use of gate valves:

  • heavy oils
  • varnish
  • light grease
  • steam
  • oil
  • gas
  • natural gas
  • honey
  • molasses
  • cream non-flammable viscous liquids
  • high pressure, high temperature steam applications

Industrial Applications

  • chemical plant
  • refinery
  • pipeline industry
  • salt working pipelines
  • power industry and any other
  • industrial facility in the world

Competitive advantage

  • AutoCAD is used to design products and optimize structures
  • Cast Process Design by by Castsoft CAD and CAE

  • Strict Manufacturing Process control

  • Quality Control Of The Casting Material

  • Metal Material Laboratory for test of compositional, metallographic & mechanical property
